* Manufactured in South Africa
* 2 year warranty
* No moving parts or fans that could malfunction

MPPT solar charge controllers perform better to standard PWM type solar panel regulators.
On average one can expect up to 30% better yields. This is because of the dynamic and intelligent way in which these controllers find and

track the maximum power delivery point of the connected solar panels, hens the abbreviation MPPT (Maximum Power Point Tracking).

Given 30% better power yield translates to a significant cost saving when buying solar panels – one simple need less total panel watts to

yield the same average power output compared to a PWM type solar regulator. In addition, the MPPT also log statistics, intelligently charges

and conditions the batteries and can be user configured for optimum system performance.

Nominal battery voltage: 12V or 24V (auto selects)
Handles panels up to: 2500W (24V system), 1250W (12V system)
Max panel voltage: 60V
Max continues battery charging current: 101A (electronically limited)

Charging (3-stages): Bulk, Absorb & Equalize
Log history: last 31 days (saves: kWh, run time and max pv watts)
Totals counter: days & kWh

Protection:
Over current protection in hardware and software
Over voltage limiting in hardware and software
Over temperature

Settings:
Charging current limit
Normal charging: voltage
Equalize charging: voltage, duration, occurrence

Weight: 4kg

Other MPPT Solar Charge Controller: 40A, 60A, 80A & 120A
